Smart EV Charger Smart EV Charger

Smart EV Charger

IC-CPD
EV MODE 2 CHARGER

  • 1.Maximize Self-Consumption of Green Energy

  • 2.Rugged Safety with Multi-Level Protection

  • 3.User-Friendly Interface with One-Touch Mode Switching

  • 4.Modular Design for Versatile Use Cases

Specifications

  • Simplicity

  • Basics

  • Professionalism

    • EACC232231C1

      EACC352231C1

    • Voltage(Vac):

      230±10%

    • Current:

      10A

      16A

    • Max Power(kW) :

      2.3

      3.5

    • Length(m) :

      5/10

    • Material:

      PC+ABS

    • Display :

      3 Color LED

    • Dimensions(L*W*H)(mm):

      206*96*56

    • Weight (kg):

      ≤1.8(5m)/≤2.3)(10m)

    • Operating Temperature(℃):

      -30~+50

    • Ingress Protection:

      IP65

    • Crushing Strength(kN):

      ≤11

    • Service Life(times):

      10000

    • Cooling:

      Natural cooling

    • Stand-by Power consumption(W):

      ＜2

    • Product Warranty(year):

      2

    Download
    file

    • SACC352231E1-5/10

    • Voltage(Vac):

      230±10%

    • Current:

      16A

    • Max Power (kW) :

      3.5

    • Length(m) :

      5/10

    • Material:

      PC+ABS

    • Display :

      2.4‘ TFT Display Screen

    • Dimensions(L*W*H)(mm):

      206*96*56

    • Weight (kg):

      ≤1.8(5m)/≤2.3)(10m)

    • Operating Temperature(℃):

      -30~+50

    • Ingress Protection:

      IP65

    • Crushing Strength(kN):

      ≤11

    • Service Life(times):

      10000

    • Cooling:

      Natural cooling

    • Stand-by Power consumption(W):

      ＜2

    • Product Warranty(year):

      2

    Download
    file

    • SACC352231S1-5/10

    • Voltage(Vac):

      230±10%

    • Current:

      8A/10A/13A/16A/Auto

    • Max Power (kW) :

      3.5

    • Length(m) :

      5/10

    • Material:

      PC+ABS

    • Display :

      2.4‘ TFT Display Screen

    • Buttons & Swith:

      Control Buttons

    • Way of Starting:

      Plug & Charge (Set Mode)

    • Communication:

      LoRa/Wi-Fi (4G)

    • Installation:

      Protable/Wall-mounted

    • Dimensions(L*W*H)(mm):

      206*96*56

    • Weight (kg):

      ≤1.8(5m)/≤2.3)(10m)

    • Operating Temperature(℃):

      -30~+50

    • Ingress Protection:

      IP65

    • Crushing Strength(kN):

      ≤11

    • Service Life(times):

      10000

    • Cooling:

      Natural cooling

    • Stand-by Power consumption(W):

      ＜2

    • Product Warranty(year):

      2

    Download
    file

    • SACC352231S2-5/10

    • Voltage(Vac):

      230±10%

    • Current:

      8A/10A/13A/16A/32A/Auto

    • Max Power (kW) :

      7

    • Length(m) :

      5/10

    • Material:

      PC+ABS

    • Display :

      2.4‘ TFT Display Screen

    • Buttons & Swith:

      Control Buttons

    • Way of Starting:

      Plug & Charge (Set Mode)/NFC

    • Communication:

      NFC/BT/LoRa/Wi-Fi (4G)

    • Installation:

      Wall-mounted

    • Dimensions(L*W*H)(mm):

      206*96*56

    • Weight (kg):

      ≤2.0(5m)/≤2.5(10m)

    • Operating Temperature(℃):

      -30~+50

    • Ingress Protection:

      IP65

    • Crushing Strength(kN):

      ≤11

    • Service Life(times):

      10000

    • Cooling:

      Natural cooling

    • Stand-by Power consumption(W):

      ＜2

    • Product Warranty(year):

      2

    Download
    file
